Install a custom FiveM-compatible minimap in under five minutes

#What is inside the resource

Every map is a complete, self-contained FiveM resource. It contains a manifest, a small client script that sets the radar zoom levels so the new texture resolution lines up, and a stream folder with the textures and geometry the game expects to find.

#Step 1 — copy the folder

Drop the unzipped folder into your resources directory. Putting it in a [standalone] or [maps] bracket folder is tidy but not required. Do not rename the folder: the manifest and the ensure line have to match.

resources/
└─ [standalone]/
   └─ pityus_minimap_orange_google/
      ├─ fxmanifest.lua
      ├─ client.lua
      └─ stream/          78 files

#Step 2 — ensure it in server.cfg

One line. Put it reasonably early — before your HUD resource — so the textures have been streamed by the time the radar first draws.

ensure pityus_minimap_orange_google

#Step 3 — remove any other minimap

This is the step people skip, and it is the single most common reason a new map does not appear. Streamed file names are global across the whole server: if two resources both ship minimap_0_0.ytd, one of them wins and which one is undefined.

Search your resources folder for the file names below and stop whatever else provides them.

# Linux / git bash
find resources -name 'minimap*.ytd' -o -name 'minimap_sea*.ytd'

# Windows PowerShell
Get-ChildItem .\resources -Recurse -Filter 'minimap*.ytd' | Select-Object FullName

#Step 4 — clear the client cache

FiveM caches streamed textures aggressively and will happily keep serving the old minimap after you have replaced it. Every client that has already connected needs the cache cleared once.

• Close FiveM completely first — the folder is locked while it runs.
• Delete the whole cache folder, not just parts of it.
• Players who have never joined your server do not need to do this.
• On a live server, announce it: without a cache clear, half your players will report the map as unchanged.

%localappdata%\FiveM\FiveM.app\data\cache

#Step 5 — verify it actually loaded

There are two separate surfaces and they fail independently, which makes the check useful for diagnosis rather than just reassurance.

1. 01 Open the pause map

   If the pause map shows the new art, the textures streamed correctly and the resource is running.

2. 02 Look at the radar

   If the pause map changed but the radar did not, the client cache was not cleared on that machine.

3. 03 If neither changed

   The resource is not running. Check the server console at start for the resource name, and check for the name collision from step 3.

#Installing through txAdmin

txAdmin does not change any of the above, it just moves where the files go. Upload the folder into the resources directory of the deployment txAdmin is managing, add the ensure line to the server.cfg txAdmin is using — which may not be the one you expect — and restart from the txAdmin panel.

#Updating to a different map later

Swapping palettes is the same four steps with one difference: stop the old minimap resource before starting the new one, or you have created exactly the name collision described above.

# in server.cfg, replace the line rather than adding a second one
# ensure pityus_minimap_blue_postal      <- old
ensure pityus_minimap_orange_google      # <- new
